9YC0 | pdb_00009yc0

Plasmodium falciparum M17 aminopeptidase (PfA-M17) bound to inhibitor 3ab (MIPS3413)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.37 Å
  • R-Value Free:
    0.271 (Depositor), 0.271 (DCC)
  • R-Value Work:
    0.218 (Depositor), 0.219 (DCC)
  • R-Value Observed:
    0.221 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Novel Scaffold Unlocks Potent Cross-Peptidase and Cross-Species Inhibitors as Promising Antimalarial Agents.

Mansouri, M.De Paoli, A.Giannangelo, C.Chowdury, M.Ngo, A.Shackleford, D.M.Webb, C.T.Lowes, K.N.Creek, D.J.Charman, S.A.Koning-Ward, T.F.McGowan, S.Scammells, P.J.

(2026) J Med Chem 69: 1358-1386

  • DOI: https://doi.org/10.1021/acs.jmedchem.5c02743
  • Primary Citation of Related Structures:
    9Y65, 9YC0, 9YC7

  • PubMed Abstract:

    Malaria remains a global health burden and the emergence of parasite-resistance to frontline drugs highlights an urgent need for new therapeutics with novel mechanisms of action. Inhibiting aminopeptidases, in particular the Plasmodium falciparum M1 and M17 aminopeptidases ( Pf A-M1 and Pf A-M17 respectively) has been shown to cause parasite death. In this study, both ligand-based and structure-based design strategies were utilized to identify novel scaffolds that act as dual inhibitors of these enzymes. Structural studies supported the improved activity showing strong hydrophobic and additional hydrogen interactions between the new cores and the S1 pocket of the enzymes. These inhibitors were highly effective against Plasmodium vivax and Plasmodium berghei , showing cross-peptidase and cross-species activity while also retaining activity against multidrug resistant P. falciparum strains. Progression to in vivo efficacy studies showed reduction in parasitaemia in mice infected with P. berghei demonstrating encouraging prospects to develop suitable drug-like candidates for the treatment of malaria.


  • Organizational Affiliation
    • Medicinal Chemistry, Monash Institute of Pharmaceutical Sciences, Monash University, Parkville, Victoria 3052, Australia.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
M17 leucyl aminopeptidase
A, B, C, D, E
A, B, C, D, E, F, G, H, I, J, K, L
527Plasmodium falciparumMutation(s): 3
EC: 3.4.11.1 (PDB Primary Data), 3.4.13 (UniProt)
UniProt
Find proteins for Q8IL11 (Plasmodium falciparum (isolate 3D7))
Explore Q8IL11
Go to UniProtKB:  Q8IL11
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IL11
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 9 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
2PE
Query on 2PE

Download Ideal Coordinates CCD File
GE [auth H],
QA [auth B]
NONAETHYLENE GLYCOL
C18 H38 O10
YZUUTMGDONTGTN-UHFFFAOYSA-N
A1CT5
Query on A1CT5

Download Ideal Coordinates CCD File
JD [auth G]N-[(1S)-1-(1,3-benzothiazol-5-yl)-2-(hydroxyamino)-2-oxoethyl]-3,3-dimethylbutanamide
C15 H19 N3 O3 S
BJEPPCMNJNEPNQ-ZDUSSCGKSA-N
A1CT4 (Subject of Investigation/LOI)
Query on A1CT4

Download Ideal Coordinates CCD File
AB [auth C]
DF [auth J]
JC [auth E]
KA [auth B]
OE [auth I]
AB [auth C],
DF [auth J],
JC [auth E],
KA [auth B],
OE [auth I],
QB [auth D],
SG [auth L],
V [auth A],
XF [auth K],
ZC [auth F],
ZD [auth H]
N-[(1R)-1-(1,3-benzothiazol-5-yl)-2-(hydroxyamino)-2-oxoethyl]-3,3-dimethylbutanamide
C15 H19 N3 O3 S
BJEPPCMNJNEPNQ-CYBMUJFWSA-N
1PE
Query on 1PE

Download Ideal Coordinates CCD File
AC [auth D]
BA [auth A]
BF [auth J]
CA [auth A]
DD [auth F]
AC [auth D],
BA [auth A],
BF [auth J],
CA [auth A],
DD [auth F],
ED [auth F],
FG [auth K],
GG [auth K],
HG [auth K],
IB [auth C],
IG [auth K],
JB [auth C],
KC [auth E],
LA [auth B],
NB [auth D],
NE [auth I],
OF [auth J],
PF [auth J],
PG [auth L],
QF [auth J],
RC [auth E],
RD [auth G],
RF [auth J],
SC [auth E],
SD [auth G],
TD [auth G],
UD [auth G],
VE [auth I],
VG [auth L],
WE [auth I],
WG [auth L],
XB [auth D],
XG [auth L],
YB [auth D],
YC [auth F],
YG [auth L],
ZB [auth D]
PENTAETHYLENE GLYCOL
C10 H22 O6
JLFNLZLINWHATN-UHFFFAOYSA-N
PEG
Query on PEG

Download Ideal Coordinates CCD File
BB [auth C]
CB [auth C]
EF [auth J]
FC [auth E]
FF [auth J]
BB [auth C],
CB [auth C],
EF [auth J],
FC [auth E],
FF [auth J],
GA [auth B],
HA [auth B],
HC [auth E],
ID [auth G],
KE [auth I],
ME [auth I],
MG [auth L],
NF [auth J],
NG [auth L],
OB [auth D],
OG [auth L],
P [auth A],
PB [auth D],
PE [auth I],
QC [auth E],
QE [auth I],
R [auth A],
RB [auth D],
RG [auth L],
S [auth A],
T [auth A],
TG [auth L],
U [auth A],
UA [auth C],
VF [auth K],
WC [auth F],
WF [auth K],
XA [auth C],
YA [auth C],
YD [auth H],
ZA [auth C]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
AA [auth A]
AD [auth F]
AG [auth K]
BD [auth F]
BE [auth H]
AA [auth A],
AD [auth F],
AG [auth K],
BD [auth F],
BE [auth H],
BG [auth K],
CD [auth F],
CE [auth H],
CF [auth J],
CG [auth K],
DE [auth H],
DG [auth K],
EB [auth C],
EE [auth H],
EG [auth K],
FB [auth C],
FE [auth H],
GB [auth C],
GC [auth E],
HB [auth C],
HF [auth J],
IC [auth E],
IF [auth J],
JF [auth J],
KF [auth J],
LC [auth E],
LD [auth G],
LF [auth J],
MC [auth E],
MD [auth G],
MF [auth J],
NA [auth B],
NC [auth E],
ND [auth G],
OA [auth B],
OC [auth E],
OD [auth G],
PA [auth B],
PC [auth E],
PD [auth G],
Q [auth A],
QD [auth G],
RE [auth I],
SB [auth D],
SE [auth I],
TB [auth D],
TE [auth I],
UB [auth D],
UE [auth I],
UG [auth L],
VB [auth D],
W [auth A],
WB [auth D],
X [auth A],
XC [auth F],
Y [auth A],
YF [auth K],
Z [auth A],
ZF [auth K]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
DMS
Query on DMS

Download Ideal Coordinates CCD File
AE [auth H]
AF [auth J]
BC [auth D]
DB [auth C]
GF [auth J]
AE [auth H],
AF [auth J],
BC [auth D],
DB [auth C],
GF [auth J],
IA [auth B],
JA [auth B],
KD [auth G],
LE [auth I],
MA [auth B],
QG [auth L],
VA [auth C],
WA [auth C]
DIMETHYL SULFOXIDE
C2 H6 O S
IAZDPXIOMUYVGZ-UHFFFAOYSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
CC [auth E]
DA [auth B]
DC [auth E]
EA [auth B]
FD [auth G]
CC [auth E],
DA [auth B],
DC [auth E],
EA [auth B],
FD [auth G],
GD [auth G],
HE [auth I],
IE [auth I],
JG [auth L],
KB [auth D],
KG [auth L],
LB [auth D],
M [auth A],
N [auth A],
RA [auth C],
SA [auth C],
SF [auth K],
TC [auth F],
TF [auth K],
UC [auth F],
VD [auth H],
WD [auth H],
XE [auth J],
YE [auth J]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
CO3
Query on CO3

Download Ideal Coordinates CCD File
EC [auth E]
FA [auth B]
HD [auth G]
JE [auth I]
LG [auth L]
EC [auth E],
FA [auth B],
HD [auth G],
JE [auth I],
LG [auth L],
MB [auth D],
O [auth A],
TA [auth C],
UF [auth K],
VC [auth F],
XD [auth H],
ZE [auth J]
CARBONATE ION
C O3
BVKZGUZCCUSVTD-UHFFFAOYSA-L
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.37 Å
  • R-Value Free:  0.271 (Depositor), 0.271 (DCC)
  • R-Value Work:  0.218 (Depositor), 0.219 (DCC)
  • R-Value Observed: 0.221 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 173.729α = 90
b = 176.51β = 90
c = 231.308γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Health and Medical Research Council (NHMRC, Australia)Australia1185354

Revision History  (Full details and data files)

  • Version 1.0: 2026-01-28
    Type: Initial release
  • Version 1.1: 2026-02-04
    Changes: Database references
