1GQA | pdb_00001gqa

Cytochrome c' from Rhodobacter Spheriodes

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:
    0.254 (Depositor)
  • R-Value Work:
    0.204 (Depositor), 0.210 (DCC)
  • R-Value Observed:
    0.209 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted HECClick on this verticalbar to view details

This is version 1.6 of the entry. See complete history.


Literature

High Resolution Crystal Structure of Ferricytochrome C' from Rhodobacter Sphaeroides

Ramirez, L.M., Axelrod, H.L., Herron, S.R., Rupp, B., Allen, J.P., Kantardjieff, K.A.

(2003) J Chem Crystallogr 33: 413


Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
CYTOCHROME C'A,
B [auth D]		130Cereibacter sphaeroidesMutation(s): 0
UniProt
Find proteins for P00148 (Cereibacter sphaeroides (strain ATCC 17023 / DSM 158 / JCM 6121 / CCUG 31486 / LMG 2827 / NBRC 12203 / NCIMB 8253 / ATH 2.4.1.))
Explore P00148
Go to UniProtKB:  P00148
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00148
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:  0.254 (Depositor)
  • R-Value Work:  0.204 (Depositor), 0.210 (DCC)
  • R-Value Observed: 0.209 (Depositor)
Space Group: P 31
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.1α = 90
b = 48.1β = 90
c = 115.798γ = 120
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
CNSphasing
EPMRphasing
REFMACrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted HECClick on this verticalbar to view details

View more in-depth experimental data
Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2002-12-19
    Type: Initial release
  • Version 1.1: 2016-12-14
    Changes: Database references, Derived calculations, Non-polymer description, Other, Version format compliance
  • Version 1.2: 2017-06-28
    Changes: Data collection
  • Version 1.3: 2019-05-08
    Changes: Data collection, Derived calculations, Experimental preparation
  • Version 1.4: 2019-05-22
    Changes: Data collection, Refinement description
  • Version 1.5: 2023-12-13
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
  • Version 1.6: 2024-11-20
    Changes: Structure summary
