2O3I | pdb_00002o3i

X-ray Crystal Structure of Protein CV_3147 from Chromobacterium violaceum. Northeast Structural Genomics Consortium Target CvR68.

PDB DOI: https://doi.org/10.2210/pdb2O3I/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Chromobacterium violaceum
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2006-12-01 Released: 2006-12-12
Deposition Author(s): Vorobiev, S.M., Chen, Y., Seetharaman, J., Cunningham, K., Ma, L.C., Janjua, H., Xiao, R., Acton, T.B., Montelione, G.T., Tong, L., Hunt, J.F., Northeast Structural Genomics Consortium (NESG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.228 (Depositor), 0.240 (DCC)
R-Value Work:
0.198 (Depositor), 0.210 (DCC)
R-Value Observed:
0.198 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.6 of the entry. See complete history.

Literature

Crystal structure of the hypothetical protein Q7NTB2_CHRVO from Chromobacterium violaceum

Vorobiev, S.M., Chen, Y., Seetharaman, J., Cunningham, K., Ma, L.C., Xiao, R., Acton, T.B., Montelione, G.T., Tong, L., Hunt, J.F.

To be published.

Macromolecule Content

Total Structure Weight: 86.56 kDa
Atom Count: 5,613
Modelled Residue Count: 751
Deposited Residue Count: 810
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hypothetical protein	A, B	405	Chromobacterium violaceum	Mutation(s): 13 Gene Names: CV_3147
UniProt
Find proteins for Q7NTB2 (Chromobacterium violaceum (strain ATCC 12472 / DSM 30191 / JCM 1249 / CCUG 213 / NBRC 12614 / NCIMB 9131 / NCTC 9757 / MK)) Explore Q7NTB2 Go to UniProtKB: Q7NTB2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q7NTB2
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free: 0.228 (Depositor), 0.240 (DCC)
R-Value Work: 0.198 (Depositor), 0.210 (DCC)
R-Value Observed: 0.198 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 92.336	α = 90
b = 125.608	β = 90
c = 65.349	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
HKL-2000	data collection
HKL-2000	data reduction
HKL-2000	data scaling
SOLVE	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2006-12-12

Deposition Author(s):

Seetharaman, J.

Montelione, G.T.

Northeast Structural Genomics Consortium (NESG)

Revision History (Full details and data files)

Version 1.0: 2006-12-12
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Version format compliance
Version 1.3: 2017-10-25
Changes: Author supporting evidence
Version 1.4: 2021-10-20
Changes: Database references, Derived calculations
Version 1.5: 2023-12-27
Changes: Data collection
Version 1.6: 2024-10-30
Changes: Structure summary
