Download MendeleyCrystal structure of the N-terminal DUF1126 in human ef-hand domain containing 2 protein
Saito, K., Olsen, S., Kishishita, S., Nishino, A., Murayama, K., Terada, T., Shirouzu, M., Kigawa, T., Yokoyama, S.To be published.
2Z14 | pdb_00002z14
Crystal structure of the N-terminal DUF1126 in human ef-hand domain containing 2 protein
- PDB DOI: https://doi.org/10.2210/pdb2Z14/pdb
- Classification: SIGNALING PROTEIN
- Organism(s): Homo sapiens
- Mutation(s): No
- Deposited: 2007-05-08 Released: 2007-11-13
Experimental Data Snapshot
- Method: X-RAY DIFFRACTION
- Resolution: 1.68 Å
- R-Value Free: 0.223 (Depositor), 0.220 (DCC)
- R-Value Work: 0.190 (Depositor), 0.190 (DCC)
- R-Value Observed: 0.190 (Depositor)
Starting Model: experimental
View more details
wwPDB Validation 3D Report Full Report
This is version 1.2 of the entry. See complete history.
Literature
To be published.
Macromolecules
Find similar proteins by:
(by identity cutoff) | 3D Structure
Entity ID: 1 | |||||
|---|---|---|---|---|---|
| Molecule | Chains | Sequence Length | Organism | Details | Image |
| EF-hand domain-containing family member C2 | 133 | Homo sapiens | Mutation(s): 0 |  | |
UniProt & NIH Common Fund Data Resources | |||||
Find proteins for Q5JST6 (Homo sapiens) Explore Q5JST6 Go to UniProtKB: Q5JST6 | |||||
PHAROS: Q5JST6 GTEx: ENSG00000183690 | |||||
Entity Groups | |||||
| Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
| UniProt Group | Q5JST6 | ||||
Sequence AnnotationsExpand | |||||
| |||||
Experimental Data & Validation
Experimental Data
- Method: X-RAY DIFFRACTION
- Resolution: 1.68 Å
- R-Value Free: 0.223 (Depositor), 0.220 (DCC)
- R-Value Work: 0.190 (Depositor), 0.190 (DCC)
- R-Value Observed: 0.190 (Depositor)
Space Group: C 1 2 1
Unit Cell:
| Length ( Å ) | Angle ( ˚ ) |
|---|---|
| a = 95.455 | α = 90 |
| b = 35.279 | β = 112.64 |
| c = 39.15 | γ = 90 |
| Software Name | Purpose |
|---|---|
| CNS | refinement |
| HKL-2000 | data reduction |
| HKL-2000 | data scaling |
| MOLREP | phasing |
Entry History
Deposition Data
- Released Date: 2007-11-13 Deposition Author(s): Saito, K., Olsen, S., Kishishita, S., Nishino, A., Murayama, K., Terada, T., Shirouzu, M., Kigawa, T., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)
Revision History (Full details and data files)
- Version 1.0: 2007-11-13
Type: Initial release - Version 1.1: 2011-07-13
Changes: Version format compliance - Version 1.2: 2023-11-01
Changes: Data collection, Database references, Refinement description
