3FA8 | pdb_00003fa8

Crystal structure of the apo R132K:Y134F:R111L:L121E mutant of cellular retinoic acid-binding protein II at 1.78 angstrom resolution

PDB DOI: https://doi.org/10.2210/pdb3FA8/pdb

Classification: TRANSPORT PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2008-11-16 Released: 2009-10-27
Deposition Author(s): Jia, X., Geiger, J.H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.78 Å
R-Value Free:
0.234 (Depositor), 0.240 (DCC)
R-Value Work:
0.179 (Depositor), 0.180 (DCC)
R-Value Observed:
0.184 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.4 of the entry. See complete history.

Literature

Crystal structures of apo cellular retinoic acid-binding protein II mutants: Structural integrity investigated through multiple site mutations

Jia, X., Lee, K.S., Vasileiou, C., Borhan, B., Geiger, J.H.

To be published.

Macromolecule Content

Total Structure Weight: 31.02 kDa
Atom Count: 2,484
Modelled Residue Count: 274
Deposited Residue Count: 274
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cellular retinoic acid-binding protein 2	A, B	137	Homo sapiens	Mutation(s): 4 Gene Names: CRABP2
UniProt & NIH Common Fund Data Resources
Find proteins for P29373 (Homo sapiens) Explore P29373 Go to UniProtKB: P29373
PHAROS: P29373 GTEx: ENSG00000143320
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P29373
Sequence Annotations Expand
Reference Sequence LOADING

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.78 Å
R-Value Free: 0.234 (Depositor), 0.240 (DCC)
R-Value Work: 0.179 (Depositor), 0.180 (DCC)
R-Value Observed: 0.184 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 34.61	α = 106.08
b = 37.169	β = 106.47
c = 60.837	γ = 89.97

Software Package:

Software Name	Purpose
HKL-2000	data collection
MOLREP	phasing
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2009-10-27

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2009-10-27
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2016-12-28
Changes: Structure summary
Version 1.3: 2021-10-20
Changes: Database references
Version 1.4: 2023-09-06
Changes: Data collection, Refinement description
